High Speed Camera LuftvisCam 2.18
Regular price
£0.00
Tax included.
Shipping calculated at checkout.
- High framerate at cost-effective price
- 1.76 Mega Pixels
- Research-grade CMOS sensor
- 10Gbps ethernet interface
- Luftvis Camera Contronller Software
- Sample video - Water Ballon
| Senor | Sony IMX Mono Global Shutter |
| Resolution | 1600*1100 |
| Framerate |
664fps Higer framerate with reduced resolutions (refer to framerate chart) |
| Pixel size | 9um |
| Exposure | 1us (minimum) |
| Bit depth | 8 bit |
| Trigger | software trigger, external trigger |
| PC Interface | PCIe 10Gbps Ethernet or Thunderbolt Adaptor Included |
Framerate: 664fps @ 1600*1100
865fps @ 1600*800
1070fps @ 1600*600
1440fps @ 1600*400
2120fps @ 1600*200
2768fps @ 1600*100
3722fps @ 1600*30
4000fps @ 1600*10
